High-Performance Dynamic Vision Sensor Specifications

Below are the detailed technical specifications of the sensor.

General Specifications

Feature	Specification
Sensor Optics	0.7 Megapixel (MP) with 1/3.03” optics
Sensor Structure	Back Side Illumination (BSI)
Effective Resolution	960 (H) × 720 (V)
Unit Pixel Size	4.95 µm
Operating Temperature	–20 °C to 70 °C
Dynamic Range	90 dB (> 3 Lx)

Performance & Speed

• Pixel Response Latency: < 1 ms (@ ambient above 10 Lx for 30% temporal contrast)
• Event Threshold (Typical): 30% @ 3 Lx ~ 100,000 Lx (Event threshold is configurable.)
• Maximum Scan Rates:
  • Compressed Frame Format: Up to 1,355 fps (Fixed)
  • RAW2 Format: Up to 1,975 fps (Fixed)
  • Variable Scan Rate: Up to 2,162 fps (Maximum)
• Transfer Formats: 32-bit compressed frame format, RAW2

Interfaces & Connectivity

• Output Interfaces: MIPI CSI-2 4-lane D-PHY (Max. 2.5 Gbps per lane)
• Input Interfaces: SPI for IMU or Gyro sensor (Max 20 MHz)
• Control Interface: CCI high-speed I2C-compatible (Two-wire serial communication circuit up to 400 KHz)
• Interrupt Interface: Capable of sending wake-up signals to external devices
• Trigger Interface: Receives and transmits external synchronization signals

Advanced Control & Features

Readout Control Functions:

• Global Hold
• Global Reset
• External Trigger

Built-in Processing Functions:

• Sub-sampling
• Cropping
• Blocking
